Laser NIR 40X
Laser specific applications for reproductive sperm analysis
Laser specific applications for reproductive sperm analysis
放大倍數(shù) Magnification | 規(guī)格型號 Model | 數(shù)值孔徑 NA | 工作距離 WD(mm) | 焦距 f’ (mm) | 分辨率 R (μm) | 焦深 DF (μm) | 物方視場 on object (mm) | 像方視場 on image (mm) | 螺紋尺寸 Screw |
40x | DZ40XNA05 | 0.50 | 3.67 | 5.0 | 0.45 | 0.59 | 5.5 | 22.0 | 0.8” |
